True Beadlock Ring for Hybrid Wheels (V2)

Finish
Bolt Color
Black Bolts
Gold Bolts
This listing is for 1 beadlock ring

Beadlock rings are for OFFROAD USE ONLY. These are NOT DOT approved for highway use

This billet beadlock ring is designed for use with our RR5-H, RR6-H and RR7-H and -H 17x8.5 Monoforged wheels. Machined from 6061-T6 aircraft grade aluminum, this ring has very high tensile strength built for off-road duty.

  • CNC laser cut precision tolerance
  • 5/8" thickness
  • The V2 ring has a knurkled surface for improved tire bite
  • Available in a Raw Billet or Black Anodized finish
  • FOR OFFROAD USE ONLY
  • Designed specifically for use with the RR5-H, RR6-H, RR7-H and -H 17x8.5 MonoForged Wheel ONLY
  • Each ring will include (25) M8 (Grade 10.9) gold or black zinc bolts
  • Weight (without hardware): 3lbs 10oz
  • Sold individually

**2024 Revision**

The beadlock ring now has 2mm more clearance to mate with tire’s with a thicker bead. This revision should make fitment more universal throughout and ease installation in some cases. This should eliminate the requirement of using “spacers” for those mounting certain select MT tires with an abnormally thick bead.

BEADLOCK RINGS ARE STRICTLY FOR OFF-ROAD USE ONLY. These are NOT DOT approved for highway use
Note: DO NOT over-torque. Improper torqueing can cause the threads to strip. Torque in a star pattern to 7 ft lbs. Once that is done, set torque wrench to 14 ft lbs.

Installation instructions can be found here


We are currently in the process of developing a DOT approved beadlock wheel. There is currently no definite timeline on this.
